Collinson silos

Poultry Feeding

At PW Maines, we want to ensure that you are equipped with the right feeding solution for your farm. We have partnered with Collinson, to provide you with the optimal automated feeding operation, which can reduce waste, avoid labour costs, avoid inconsistency and ensure fresh feed at all times, keeping your flock safe and healthy.

Did you know? – Collinson Silos are constructed from galvanised steel or a choice of 6 Plasteel finishes for long life. Plasteel colours can be selected to match your buildings, fit in with the surroundings or to comply with the requirements of the local planning authority. This finish also adds an additional protection layer in coastal locations

County S1 Range

CENTRE DISCHARGE



The 60° cone on the S1 silos has been designed with pelleted products and whole grains in mind, allowing them to discharge freely from the silo into a bag, barrow or conveyor whilst ensuring that feed is stored in the optimum condition for your animals

  • level indicators allow you to keep a visual check on how much feed is left in the silo
  • The heavy duty 5mm filler pipe bend gently sweeps over the roof of the silo, minimising pellet degradation
  • To aid biosecurity on site, the autovent closes during pneumatic filling, diverting dust laden air away from the roof, which may otherwise attract birds and vermin. To enhance bio-security measures, fit a Cyclone Dust Collector to the exhaust pipe to eliminate all dust
s1_gal
S3 Silo

County S3 Range

CENTRE DISCHARGE



Meal and mealy products have sluggish flow characteristics so the S3 is designed with a steep 67° cone to give the optimum feed flow from the silo. This design enables feed to discharge freely into conveyor systems, bags or barrows. The S3 is also suitable for nuts, pellets and wholegrains making it a universal silo so should your feeding arrangements change in the future, your silo won’t need to.

  • An S3 Silo in conjunction with a fast unloading auger provides a simple solution for filling your mixer wagon.
  • To aid biosecurity on site, the autovent closes during pneumatic filling, diverting dust laden air away from the roof, which may otherwise attract birds and vermin. To enhance bio-security measures, fit a cyclone dust collector to the exhaust pipe to eliminate all dust
  • When filling the silo, the top bend is the first point on impact for your feed. Our heavy duty 5mm walled filler bend protects against the wear and tear of the more abrasive feed types, maximising longevity of your filler pipe
  • The filler pipe design enables a lock to be fitted so you can ensure the right product is delivered to the right silo, this is often required when medicated feeds are being delivered

County T1 Range

Centre Discharge

The T1 Silo with a 60° cone lends itself ideally to storing free flowing pelleted products or wholegrains. Fill bags, barrows and conveyor systems or for additional versatility from this three legged silo, add extra leg length and utilise the multi position chute to discharge easily and directly into your snacker, front end loader or barrow.

Collinson Silos

There is a Collinson silo to suit everyone’s needs. Designed to accommodate a range of feeds and to suit many different applications and budgets; from a small capacity pick up, mobile silos, kit form models right through to the Premium County Range.
